SPECIFICATIONS

Battery: 12V 45Ah lead acidLG; 72V 60AH Lithium battery

Brake System: Front disc+Rear dsic

Brake system: Front/rear disc

Charger: 110-240V/50-60HZ

Charging time: 6 hours

Climbing Capacity: >40 degree

Color available: Black, Red

Curb Weight: 100 ~ 200 kg

Differential Lock: Unequipped

Driving Type: 2WD

Engine Type: 4-Stroke

Grade Ability: ≥25°

Load Capacity: 150KG

Max speed: 55km/h

Maximum Speed: ≤50Km/h

Maximum Torque(Nm): ≥80Nm

Minimum Grand Clearance: 200-250mm

Motor power: 60V 1200W;72V 2000W Brushless DC motor

Power: > 1000W

Tire Size: 10 inch,Front 23*7-10Rear 22*10.0-10 Aluminum rim

Transmission System: Shaft Drive

Voltage: 60 V

Wheelbase: 1000-1400mm

Motor	60V 1200W.72V 2000W Brushless DC motor
Battery	5pcs x 12V 45Ah lead acidLG 72V 60AH Lithium battery
Charge period	8-10hours 4-8 hours (lithium ) charging current10AH
Battery-life	300 cycles 800 Cycles ( lithium )
Max torque(N·M)	84
Max speed	50km/h(1200W) 55Km/h(2000W) Max distance range:55km(1200W) 75km(2000W)
Max climbing angle	40
Load capacity	<150kg
Rim	Aluminum
Charger	110-240V/50-60HZ
Wheelbase	1200mm
Head light	12V35W
Brake system	Front/rear disc
Brake	Front/manual,rear/manual
Tyre size	Front 23*7-10Rear 22*10.0-10 Aluminum rim
Colour	Red,Blue,Green,Black,etc

Packaging and Shipping

To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.

Net weight: 162kgs
Gross weight: 186kgs
Carton size:1580x840x760mm
Product size:1830x1100x1100mm

Qty: 20pcs/20,42pcs/40,42pcs/40HQ
